Aluminum frame. 24 kg. Carries 100 kg. Rolls anywhere, lifts 490 mm on a manual hydraulic pump, and one person can actually carry it between stations. CE certified to EN 1570. Half the price of the branded catalog — because the price of aluminum and a hydraulic pump hasn't doubled just because someone else put their name on it.
3/4 view
CE · EN 1570 · 24 kg · ALUMINUM
Most scissor lift tables weigh 200–900 kg and stay where you bolt them. The JL-MSL weighs 24 kg. One person picks it up and carries it to the next workstation. Four φ100 mm caster wheels mean you can also roll it — and when you get it where you need it, the manual hydraulic pump raises a 100 kg load up to 755 mm in a few strokes. The platform is 700 × 450 mm — enough space for a box, a component tray, or a mid-sized bin.
The aluminum frame is what makes it portable. Steel lift carts at this capacity run 50–80 kg — the aluminum cuts that roughly in half without compromising the 100 kg load rating or the EN 1570 compliance. The hydraulic circuit is a sealed unit; you're not fighting rust or contamination in the pump after a few months of shop floor use.
Assembly lines where the lift point changes every week. Electronics benches where components need to come up to eye level. Workshops where you need an occasional lift at two or three different stations and don't want a fixed table bolted to each one. The JL-MSL moves with the work — which is the point.
Ships in an 850 × 490 × 300 mm carton at 24 kg. It fits in the back of a standard cargo van. If your team needs more than one, they stack efficiently for delivery.
Single model, single spec sheet — no variant confusion.
| Specification | JL-MSL (ALT10) |
|---|---|
| Rated capacity | 100 kg |
| Platform size | 700 × 450 mm |
| Min. height (lowered) | 265 mm |
| Max. height (raised) | 755 mm |
| Lift height range | 490 mm |
| Net weight | 24 kg |
| Wheel diameter | φ100 mm casters |
| Frame material | Aluminum alloy construction |
| Lift mechanism | Manual hydraulic pump |
| Certification | CE · EN 1570 |
| Package size | 850 × 490 × 300 mm |
| Origin | Manufactured in Jiangsu, China · QC'd & shipped from Toronto, Ontario |
All specs verified against the factory data sheet shipped with the unit. Single model — no variants or options to configure.
Fixed lift tables solve one station. The JL-MSL solves the whole floor — because it goes where the work is, not the other way around.
Steel competitors at this capacity weigh 50–80 kg. The aluminum construction cuts the unit weight roughly in half — one person can genuinely carry it between workstations.
From 265 mm up to 755 mm — enough range to go from floor-level pick to comfortable standing work height, or to match ergonomic bench heights across different operators.
Pump strokes are light — aluminum frame means you're not fighting the dead weight of the unit, just lifting the load.
φ100 mm wheels roll freely on smooth and lightly textured floors. Roll it to the station, position it, lock the pump and lift. No carrying required if the floor is clear.
Meets the European scissor lift table safety standard. CE Declaration of Conformity ships in the carton with the unit — no portal, no follow-up request.
850 × 490 × 300 mm carton at 24 kg. Fits in a cargo van. If you order multiples, they stack. Delivery doesn't require a loading dock or a pallet jack.
Every JL-MSL ships with the documentation a procurement team or safety officer actually asks for, packed in the carton with the unit.
A portable aluminum scissor lift at 100 kg capacity isn't a complex piece of engineering. What you're paying for in the branded catalog is the distributor margin, the field sales rep, and the brand badge — not better aluminum.
| Model | Brand catalog list | Jesterlift | Savings |
|---|---|---|---|
| JL-MSL — 100 kg portable aluminum mobile scissor lift table | $2,200 | $1,190 | −46% ($1,010) |
Prices in CAD · CE certified · EN 1570 compliant · aluminum frame · manual hydraulic · QC pack included · FOB Toronto. Brand catalog list = estimated CAD list price for comparable branded portable aluminum lift tables; exact branded pricing is quote-gated.
Same Jiangsu factory. Same aluminum frame. Same EN 1570 certification. We publish the price the rest of the catalog hides — because a portable lift table isn't a capital investment, it's a tool.
No portal, no sales gate. Send your quantity and timeline — we'll come back with a published price, lead time and the QC pack contents, usually within one business day.
